0121-108-0001

Inventory Number Title HTML Tag Instruction Manual_1 Instruction Manual_2 0221-068-0003 Hartness, 935, Packaging System, 264 L x 85 H x 68 W in., 5580 lbs. " Product Overview: Hartness, Model 935, automatic, intermittent motion, descending, soft drop case packer. Rated from 5 to 30 cases per minute with number of product depending on materials, application and machine configuration. Case size range: 7"" to 22½"" in Length; 5½"" to 16½"" in Width; 2"" to 19"" in Height. Container size range: 2 oz to 2½ gallons and can handle glass, and plastic round containers of various sizes and shapes (all with proper change parts). Equipped with dual side belt lane divert-er, 155"" long accumulation with adjustable width product lane dividers, air bladder container stops, (2) 3½"" wide x 64"" long bottom case in feed conveyors to choke feed thru product drop area with descending product soft drop into the case. Control panel has AB controller with an AB touchscreen HMI. Mounted on heavy duty base frame with leveling legs. The Frain Advantages: • Complete Line Integration • Machinery Retrofit and Recondition • In-House Testing, Proof of Concept, Trial Runs • On-Site Installation and Training • Factory Acceptance Testing Product Features: • Safety Guarding • Elevator Safety Lock • Mac Valve Update • Electrical Updates/PLC & HMI Updates • Laner Drives and Motors • Case Feed Lug Chain • Flap Orienter and Active Plow • Dual Case Option • Square Case Option • Heavy Duty Elevator • Narrow Dead Plate (1.5') • EZ-Change Grid Cart Systems • Intelligent Lighting Kit General: Manufacturer: Hartness Model Name: Packaging System Model Number/MPN: 935 Inventory Number: 0221-068-0003 Series: W935117 Condition: Used Specifications: Aisle: 09B Bay: 3500 Weight (lb): 5580 lbs. OAD: 264 L x 85 H x 68 W in. " 0221-163-0003 Yield Enhancement Solutions, YTV2050, Aoi System, 2425 lbs. " Product Overview: Automated optical inspection (AOI) and automated X-ray inspection (AXI) have been around for some time in various configurations and both have played a role in improving the quality of circuit boards. While some companies opt for one technology over the other, each form of inspection contributes its own unique benefit to the manufacturing process. As board densities increase and component sizes decrease, the need for a fast, accurate, and more efficient inspection process is critical. A growing number of electronics assemblers have integrated AOI and AXI into their quality-control inspection processes. Opting for both types of inspection can provide even greater benefits and return on investment as has been found by Biamp Systems, an international provider of professional installed audio electronics. The company, headquartered in Beaverton, OR, with additional engineering operations in Brisbane, Australia, delivers high-quality and innovative professional electronic products designed to meet the audio requirements of corporate boardrooms, theater complexes, courtrooms, public venues, and other installed audio applications. In March 2005, Biamp was looking for ways to make the inspection process on a surface-mount line more efficient. Several inspectors would visually check the circuit boards with the aid of template overlays and paper documentation, such as drawings and the bill of materials. Visual inspection consumed a good part of the operators’ time, and in many cases, there was a lag between the time boards were processed and inspected. When comparing the speed, efficiency, and flexibility of other test and inspection methods, the benefits of AOI were clear. A typical manufacturing line, for example, may have two to four inspectors to visually identify and repair component and solder defects. By contrast, an AOI system requires only one operator to detect and repair defects as well as collect all necessary data for yield improvements. This can reduce the per-shift requirement for labor or enable reallocation of resources to another part of the manufacturing process. Biamp purchased an AOI machine to better utilize operator time and automate quality data collection. Ease of use is one important but often overlooked factor to consider when implementing AOI. For dedicated higher volume production lines, some systems are better suited than others, which often are programming-intensive and do not lend themselves to line changeover. Other types of systems are designed to provide the flexibility needed to match production throughput on multiple line configurations. Biamp was looking for something simple to program, easy to operate, and available at a competitive price. The company selected the YESTech YTV-2050 AOI machine. The YTV-2050 is a high-speed, high-defect coverage AOI system. Image processing technology integrates several techniques including color, normalized correlation, and rule-based algorithms to provide inspection coverage with a low false failure rate. It uses Thin Camera™ technology and has up to four top-down viewing cameras and four side-viewing cameras to inspect solder joints and verify correct part assembly. Technicians typically take less than 45 minutes to create a complete program including solder inspection. A standard package library simplifies training and ensures program portability across manufacturing lines. Off-line programming maximizes machine utilization, and real-time statistical process control monitoring provides a valuable yield enhancement solution. With Biamp’s commitment to comply with the European restriction of hazardous substances (RoHS) initiative in 2006, the company added a second surface-mount line along with a newly released YESTech F1S AOI machine. The new platform could better accommodate Biamp’s higher speed line with faster inspection time, more accurate motion control, and LED lighting. The system’s four oblique viewing cameras offered inspection capabilities for R-nets and other difficult-to-inspect parts. Product Features: • Capture on the fly technology • 3D Fusion Lighting (RGB+White LED's) • 5 megapixel color imaging • 2 top-down and 4 side angle cameras • Quick set-up • High speed, high defect coverage • Low false failure rate • Programmable conveyor for boards up to 20 x 22 • Equally effective for paste, pre / post-reflow and final assembly inspection • Off-line programming maximizes machine utilization and real-time SPC monitoring provides a valuable yield enhancement solution General: Manufacturer: Yield Enhancement Solutions Model Name: Aoi System Model Number/MPN: YTV2050 Inventory Number: 0221-163-0003 Series: V10412113 Condition: Used Specifications: Aisle: 09A Bay: 2500 Weight (lb): 2425 lbs. " 0221-163-0002 Yield Enhancement Solutions, YTV2050, Aoi System, 2375 lbs. " Product Overview: Automated optical inspection (AOI) and automated X-ray inspection (AXI) have been around for some time in various configurations and both have played a role in improving the quality of circuit boards. While some companies opt for one technology over the other, each form of inspection contributes its own unique benefit to the manufacturing process. As board densities increase and component sizes decrease, the need for a fast, accurate, and more efficient inspection process is critical. A growing number of electronics assemblers have integrated AOI and AXI into their quality-control inspection processes. Opting for both types of inspection can provide even greater benefits and return on investment as has been found by Biamp Systems, an international provider of professional installed audio electronics. The company, headquartered in Beaverton, OR, with additional engineering operations in Brisbane, Australia, delivers high-quality and innovative professional electronic products designed to meet the audio requirements of corporate boardrooms, theater complexes, courtrooms, public venues, and other installed audio applications. In March 2005, Biamp was looking for ways to make the inspection process on a surface-mount line more efficient. Several inspectors would visually check the circuit boards with the aid of template overlays and paper documentation, such as drawings and the bill of materials. Visual inspection consumed a good part of the operators’ time, and in many cases, there was a lag between the time boards were processed and inspected. When comparing the speed, efficiency, and flexibility of other test and inspection methods, the benefits of AOI were clear. A typical manufacturing line, for example, may have two to four inspectors to visually identify and repair component and solder defects. By contrast, an AOI system requires only one operator to detect and repair defects as well as collect all necessary data for yield improvements. This can reduce the per-shift requirement for labor or enable reallocation of resources to another part of the manufacturing process. Biamp purchased an AOI machine to better utilize operator time and automate quality data collection. Ease of use is one important but often overlooked factor to consider when implementing AOI. For dedicated higher volume production lines, some systems are better suited than others, which often are programming-intensive and do not lend themselves to line changeover. Other types of systems are designed to provide the flexibility needed to match production throughput on multiple line configurations. Biamp was looking for something simple to program, easy to operate, and available at a competitive price. The company selected the YESTech YTV-2050 AOI machine. The YTV-2050 is a high-speed, high-defect coverage AOI system. Image processing technology integrates several techniques including color, normalized correlation, and rule-based algorithms to provide inspection coverage with a low false failure rate. It uses Thin Camera™ technology and has up to four top-down viewing cameras and four side-viewing cameras to inspect solder joints and verify correct part assembly. Technicians typically take less than 45 minutes to create a complete program including solder inspection. A standard package library simplifies training and ensures program portability across manufacturing lines. Off-line programming maximizes machine utilization, and real-time statistical process control monitoring provides a valuable yield enhancement solution. With Biamp’s commitment to comply with the European restriction of hazardous substances (RoHS) initiative in 2006, the company added a second surface-mount line along with a newly released YESTech F1S AOI machine. The new platform could better accommodate Biamp’s higher speed line with faster inspection time, more accurate motion control, and LED lighting. The system’s four oblique viewing cameras offered inspection capabilities for R-nets and other difficult-to-inspect parts. Product Features: • Capture on the fly technology • 3D Fusion Lighting (RGB+White LED's) • 5 megapixel color imaging • 2 top-down and 4 side angle cameras • Quick set-up • High speed, high defect coverage • Low false failure rate • Programmable conveyor for boards up to 20 x 22 • Equally effective for paste, pre / post-reflow and final assembly inspection • Off-line programming maximizes machine utilization and real-time SPC monitoring provides a valuable yield enhancement solution General: Manufacturer: Yield Enhancement Solutions Model Name: Aoi System Model Number/MPN: YTV2050 Inventory Number: 0221-163-0002 Series: V20411100 Make Year: 2004 Condition: Used Specifications: Aisle: 09A Bay: 2500 Weight (lb): 2375 lbs. " 0221-163-0001 Pva, UV5000, Ultra Violet Curing Oven, 220V ac, 50/60 Hz, 550 lbs. " Product Overview: The UV5000 is a compact UV curing module suitable for high intensity, rapid curing of UV coatings, adhesives, and inks. Each lamp features UV light in a concentrated 12.7 cm x 12.7 cm (5” x 5”) area primarily in the UV-A range (320-390 mm wave length). Lamps are easily combined to offer curing widths out to 508 mm (20 in). Product Features: • Edge carrying, variable speed pin chain conveyor • Rail expansion compensation • SMEMA communication protocol • Power supply and reflector housing • Longwave, shortwave, and visible UV bulbs available • Graphic LCD display with keypad • 2000 hour manufacturer’s bulb warranty • Easy UV lamp access via overhead hatch door General: Manufacturer: Pva Model Name: Ultra Violet Curing Oven Model Number/MPN: UV5000 Inventory Number: 0221-163-0001 Make Year: 2010 Specifications: Aisle: 09A Bay: 1400 Weight (lb): 550 lbs. Capacity: U196 Power Requirements: 220VAC, +/-10%, 50/60 Hz UV Cure Lamps: 400W Metal Halide Bulb UV Cure Width: 5, 10, 15 or 20 in. standard Conveyor Speed: 0.3 m/min to 5.8 m/min (1 ft./min to 19 ft./min) Board/Pallet Width: 51 to 508 mm (2 to 20 in.) Component Clearance: 76.2 mm (3 in.) Conveyor Height: 940 to 965 mm from floor (37 to 38 in., SMEMA standard) Exhaust: 6 in. Flange provided " 0221-072-0005 National, NH5212, Hydraulic Shear, 52 in. 12 gauge Capacity, 1540 lbs. " Product Overview: National heavy duty power shears are equipped with a fully integrated hydraulic unit. Complete with electrical hydraulic valve, pilot operated pressure relief valve, heavy duty foot switch, heavy duty double acting cylinders, and a fully enclosed control panel. National hydraulic shears are actuated by a portable shrouded electric foot switch attached to a long flexible cable so it may be placed in a comfortable position for the operator. They are constructed with an extra heavy cast iron body with solid, 4-edge high carbon, and high chromium blade and feature a quick adjusting back gauge for direct reading with a positive lock. Table gauges and front arm extensions are standard. Product Features: • Heavy cast iron body • Four cutting edge high carbon, high chromium blades • Actuated by electric foot switch • Standard back gauges General: Manufacturer: National Model Name: Hydraulic Shear Model Number/MPN: NH5212 Inventory Number: 0221-072-0005 Series: 8850985 Specifications: Aisle: 04A Bay: 3000 Weight (lb): 1540 lbs. Capacity: 52 in. 12 gauge Type: Hydraulic Mild Steel Capacity: 12 gauge (2.6 mm) Stainless Capacity: 16 gauge (1.6 mm) Cutting Length (inches): 52 Cutting Width (inches): 52 Dimensions: 61 L x 43 H x 76 W " https://www.trick-tools.com/common/documentation/nh5212_manual.pdf 0221-082-0027 Schleuniger, POWER STRIP 9500, Wire Stripper, 280 lbs. " Product Overview: Cathode Lighting Systems in Gaithersburg, MD is the world’s premier manufacturer of specification-grade, modular cold-cathode fixtures and lamps. Because of the high quality product it produces, the company has come to be known as “the gold standard” in architectural cove lighting. In order to achieve such a superior product, Cathode Lighting Systems uses only the highest quality machinery in its manufacturing process. Part of this manufacturing process consists of creating a custom cable design that includes cutting, window stripping and stripping the ends of the cable. According to the company’s President, Steve Grossman, this process would be a “disaster” if it were done by hand because the material is very difficult to strip and the time investment needed would be unrealistic. Understanding that the automation of this process was the key to cost-effective production, Grossman conducted research to find a solution that would meet his needs for cost efficiency, quality and automation. Cathode Lighting Systems chose the PowerStrip 9500 automatic cut and strip machine from Schleuniger. This machine is able to cut, strip and window strip cables in one easy automated step, giving Grossman the automation and cost efficiency he was looking for. “With the cost savings we achieved, the machine paid for itself within one year,” says Grossman. Its innovative design enables the PowerStrip 9500 to process many different types of applications, including Cathode Lighting System’s difficult to strip cable, with precise and repeatable stripping quality, upholding Cathode Lighting Systems’ high standards. “The machine is well made and runs flawlessly,” Grossman added. “I wish everything would run this well.” Automatic Cut & Strip Machine with Rotary Cutting Unit and Saw Module The PowerStrip 9500 SAW is a fully automatic wire cutting and stripping machine with the addition of a saw module for the precision cutting of various materials, such as POF and Sucoform cables. The system is based on field proven Schleuniger PowerStrip family of cutting and stripping machines. The PowerStrip 9500 SAW is available in two base units: • PowerStrip 9500 P/SAW: A fully automatic cutting and stripping machine with programmable multi-blade cutter head and sawing unit. • PowerStrip 9500 RSL/SAW: A fully automatic cutting and stripping machine with programmable multi-blade cutter head, sawing unit and programmable rotary cutting unit. The use of the saw is controlled by the PowerStrip 9500 and is stored with the cable program in memory. The actual sawing process is managed by a separate control system in the saw module. Parameters for the saw module and blade selection are set at Schleuniger based on samples provided by the customer. Product Features: • Sawing Unit • Arbor for standard saw blades • Adjustable speed (factory set per customer supplied samples) • Connection for extraction system • Pneumatic saw feed • Clamping means • Double pneumatic clamping supports • Retainer for cable specific clamping jaws The PowerStrip 9500 P/SAW and RSL/SAW combine a precision sawing process with all of the advantages of the Schleuniger PowerStrip 9500: • Clean, square cut without any damage to the cable surface • Heavy-duty cutting and stripping unit • High flexibility with the multi-blade cutter head and wide range of available blades and tooling • Short changeover time since most parameters are stored in memory • Easy programming and adjustment directly on the machine or with Schleuniger Cayman cable processing software The individual processes are combined in a user friendly system to achieve the highest process quality and production throughput, assuring economic efficiency is achieved. Options: • Customer specific jaws and guide parts • Saw blades made of different materials and with different cutting geometries The PowerStrip 9500 SAW makes it possible to process applications which are restricted or impossible with other common cutting processes: • POF, the clean saw cut guarantees a perfect end surface with low insertion loss. This eliminates the need for subsequent grinding, polishing or hot plating. • Sucoform, the solid inner conductor is cut cleanly and at right angle with the cable axis. General: Manufacturer: Schleuniger Model Name: Wire Stripper Model Number/MPN: POWER STRIP 9500 Inventory Number: 0221-082-0027 Series: 3033-2007 Make Year: 2007 Specifications: Aisle: 04A Bay: 2000 Weight (lb): 280 lbs. Saw Blade Diameter: 80 mm Revolutions/minute: 3000 to 4000 rpm (factory set) Minimum Cable Length: 140 mm Interface: Hot-Stamp or CAN " 0321-046-0028 Videojet, 1560, Printer, 10.4 in. Color Touchscreen, 140 lbs. " Product Overview: The Videojet 1560 CIJ Printer features advanced technology and on-board tools to minimise downtime and reduce cost of ownership. When uptime and availability are critical and Overall Equipment Effectiveness (OEE) is your goal, the Videojet 1560 is for you. Its advanced features and tools help minimize planned and unplanned downtime and maximize printer Availability. With Long Life Core™ technology, the 1560 is guaranteed to deliver five years of operation between planned wear parts replacement. Product Features: Speed Without Compromising Quality: • Dynamic Calibration™ adjusts jetting parameters automatically to help ensure high quality print • Print 1 to 5 lines of print for a range of coding needs: • Single line max speed = 279 m/min (914 ft/min) • Dual line max speed = 81 m/min (267 ft/min) • Tri-line max speed = 36 m/min (119 ft/min) Engineered for Extended Runs; Uptime Advantage Via: • CleanFlow™ technology resists ink buildup that can cause ordinary inkjet printers to shut down • Long Life Core™ technology delivers five years of guaranteed operation between planned wear parts replacement (1) • Internal pump means no external air, minimising potential for contaminants to enter ink stream • Auto cleaning printhead for fast start-ups, even after extended shutdowns No Mess, No Waste Fluid Delivery: • Make-up consumption as low as 2.4 ml/hour • Smart Cartridge™ fluid delivery system to virtually eliminate spills and help ensure the correct fluids are being used • On-board Code Assurance to help prevent coding mistakes: • Advanced software minimises and mistake-proofs operator inputs to the coding and marking process to help reduce errors • Operator inputs are governed by rules which simplifies choices via field prompts, drop-down menus, calendar displays and predefined formats to help ensure correct entries Built-In Productivity Tools to Keep Your Lines Operational: • Bright, 10.4 inch colour touchscreen interface that provides real-time fluid levels, maintenance alerts, print jobs and other operational information • Instant fault information is displayed to get your printer and line running again fast • Drill down into Printer Availability data to discover technical and operational causes of downtime, get to the root cause of downtime events and fix them for good General: Manufacturer: Videojet Model Name: Printer Model Number/MPN: 1560 Inventory Number: 0321-046-0028 Series: 17074014C46ZH Make Year: 2017 Specifications: Aisle: 12B Bay: 3400 Weight (lb): 140 lbs. Printheads: 1 Inks: Dye Based Maximum Lines of Print: 5 Maximum Line Speed (1): 279 m/min (914 ft/min) Environmental Protection: IP55 (IP65 optional) Umbilical Length: 3 m (9.8 ft.) optional 6 m (19.6 ft.) Message Storage Capability: 250 Smart Cartridge™: Included Plug and Play Printhead Modules: Included USB: Included Communications: Ethernet and RS-232 Serial Positive Air / CleanFlow™: Included Display (User Interface): CLARiTY® based 10.4 inch color touchscreen " 0321-046-0012 Videojet, 1560, Printer, 10.4 in. Color Touchscreen, 63 lbs. " Product Overview: The Videojet 1560 CIJ Printer features advanced technology and on-board tools to minimise downtime and reduce cost of ownership. When uptime and availability are critical and Overall Equipment Effectiveness (OEE) is your goal, the Videojet 1560 is for you. Its advanced features and tools help minimize planned and unplanned downtime and maximize printer Availability. With Long Life Core™ technology, the 1560 is guaranteed to deliver five years of operation between planned wear parts replacement. Product Features: Speed Without Compromising Quality: • Dynamic Calibration™ adjusts jetting parameters automatically to help ensure high quality print • Print 1 to 5 lines of print for a range of coding needs: • Single line max speed = 279 m/min (914 ft/min) • Dual line max speed = 81 m/min (267 ft/min) • Tri-line max speed = 36 m/min (119 ft/min) Engineered for Extended Runs; Uptime Advantage Via: • CleanFlow™ technology resists ink buildup that can cause ordinary inkjet printers to shut down • Long Life Core™ technology delivers five years of guaranteed operation between planned wear parts replacement (1) • Internal pump means no external air, minimising potential for contaminants to enter ink stream • Auto cleaning printhead for fast start-ups, even after extended shutdowns No Mess, No Waste Fluid Delivery: • Make-up consumption as low as 2.4 ml/hour • Smart Cartridge™ fluid delivery system to virtually eliminate spills and help ensure the correct fluids are being used • On-board Code Assurance to help prevent coding mistakes: • Advanced software minimises and mistake-proofs operator inputs to the coding and marking process to help reduce errors • Operator inputs are governed by rules which simplifies choices via field prompts, drop-down menus, calendar displays and predefined formats to help ensure correct entries Built-In Productivity Tools to Keep Your Lines Operational: • Bright, 10.4 inch colour touchscreen interface that provides real-time fluid levels, maintenance alerts, print jobs and other operational information • Instant fault information is displayed to get your printer and line running again fast • Drill down into Printer Availability data to discover technical and operational causes of downtime, get to the root cause of downtime events and fix them for good General: Manufacturer: Videojet Model Name: Printer Model Number/MPN: 1560 Inventory Number: 0321-046-0012 Series: 17165004C46ZH Make Year: 2017 Specifications: Aisle: 12A Bay: 3100 Weight (lb): 63 lbs. Printheads: 1 Inks: Dye Based Maximum Lines of Print: 5 Maximum Line Speed (1): 279 m/min (914 ft/min) Environmental Protection: IP55 (IP65 optional) Umbilical Length: 3 m (9.8 ft.) optional 6 m (19.6 ft.) Message Storage Capability: 250 Smart Cartridge™: Included Plug and Play Printhead Modules: Included USB: Included Communications: Ethernet and RS-232 Serial Positive Air / CleanFlow™: Included Display (User Interface): CLARiTY® based 10.4 inch color touchscreen " 0321-046-0011 Videojet, 1560, Printer, 10.4 in. Color Touchscreen, 63 lbs. " Product Overview: The Videojet 1560 CIJ Printer features advanced technology and on-board tools to minimise downtime and reduce cost of ownership. When uptime and availability are critical and Overall Equipment Effectiveness (OEE) is your goal, the Videojet 1560 is for you. Its advanced features and tools help minimize planned and unplanned downtime and maximize printer Availability. With Long Life Core™ technology, the 1560 is guaranteed to deliver five years of operation between planned wear parts replacement. Product Features: Speed Without Compromising Quality: • Dynamic Calibration™ adjusts jetting parameters automatically to help ensure high quality print • Print 1 to 5 lines of print for a range of coding needs: • Single line max speed = 279 m/min (914 ft/min) • Dual line max speed = 81 m/min (267 ft/min) • Tri-line max speed = 36 m/min (119 ft/min) Engineered for Extended Runs; Uptime Advantage Via: • CleanFlow™ technology resists ink buildup that can cause ordinary inkjet printers to shut down • Long Life Core™ technology delivers five years of guaranteed operation between planned wear parts replacement (1) • Internal pump means no external air, minimising potential for contaminants to enter ink stream • Auto cleaning printhead for fast start-ups, even after extended shutdowns No Mess, No Waste Fluid Delivery: • Make-up consumption as low as 2.4 ml/hour • Smart Cartridge™ fluid delivery system to virtually eliminate spills and help ensure the correct fluids are being used • On-board Code Assurance to help prevent coding mistakes: • Advanced software minimises and mistake-proofs operator inputs to the coding and marking process to help reduce errors • Operator inputs are governed by rules which simplifies choices via field prompts, drop-down menus, calendar displays and predefined formats to help ensure correct entries Built-In Productivity Tools to Keep Your Lines Operational: • Bright, 10.4 inch colour touchscreen interface that provides real-time fluid levels, maintenance alerts, print jobs and other operational information • Instant fault information is displayed to get your printer and line running again fast • Drill down into Printer Availability data to discover technical and operational causes of downtime, get to the root cause of downtime events and fix them for good General: Manufacturer: Videojet Model Name: Printer Model Number/MPN: 1560 Inventory Number: 0321-046-0011 Series: 17158008C46ZH Make Year: 2017 Specifications: Aisle: 12A Bay: 3100 Weight (lb): 63 lbs. Printheads: 1 Inks: Dye Based Maximum Lines of Print: 5 Maximum Line Speed (1): 279 m/min (914 ft/min) Environmental Protection: IP55 (IP65 optional) Umbilical Length: 3 m (9.8 ft.) optional 6 m (19.6 ft.) Message Storage Capability: 250 Smart Cartridge™: Included Plug and Play Printhead Modules: Included USB: Included Communications: Ethernet and RS-232 Serial Positive Air / CleanFlow™: Included Display (User Interface): CLARiTY® based 10.4 inch color touchscreen " 0321-046-0008 Videojet, 1560, Printer, 10.4 in. Color Touchscreen, 63 lbs. " Product Overview: The Videojet 1560 CIJ Printer features advanced technology and on-board tools to minimise downtime and reduce cost of ownership. When uptime and availability are critical and Overall Equipment Effectiveness (OEE) is your goal, the Videojet 1560 is for you. Its advanced features and tools help minimize planned and unplanned downtime and maximize printer Availability. With Long Life Core™ technology, the 1560 is guaranteed to deliver five years of operation between planned wear parts replacement. Product Features: Speed Without Compromising Quality: • Dynamic Calibration™ adjusts jetting parameters automatically to help ensure high quality print • Print 1 to 5 lines of print for a range of coding needs: • Single line max speed = 279 m/min (914 ft/min) • Dual line max speed = 81 m/min (267 ft/min) • Tri-line max speed = 36 m/min (119 ft/min) Engineered for Extended Runs; Uptime Advantage Via: • CleanFlow™ technology resists ink buildup that can cause ordinary inkjet printers to shut down • Long Life Core™ technology delivers five years of guaranteed operation between planned wear parts replacement (1) • Internal pump means no external air, minimising potential for contaminants to enter ink stream • Auto cleaning printhead for fast start-ups, even after extended shutdowns No Mess, No Waste Fluid Delivery: • Make-up consumption as low as 2.4 ml/hour • Smart Cartridge™ fluid delivery system to virtually eliminate spills and help ensure the correct fluids are being used • On-board Code Assurance to help prevent coding mistakes: • Advanced software minimises and mistake-proofs operator inputs to the coding and marking process to help reduce errors • Operator inputs are governed by rules which simplifies choices via field prompts, drop-down menus, calendar displays and predefined formats to help ensure correct entries Built-In Productivity Tools to Keep Your Lines Operational: • Bright, 10.4 inch colour touchscreen interface that provides real-time fluid levels, maintenance alerts, print jobs and other operational information • Instant fault information is displayed to get your printer and line running again fast • Drill down into Printer Availability data to discover technical and operational causes of downtime, get to the root cause of downtime events and fix them for good General: Manufacturer: Videojet Model Name: Printer Model Number/MPN: 1560 Inventory Number: 0321-046-0008 Series: 17017002C46ZH Make Year: 2017 Specifications: Aisle: 12B Bay: 3100 Weight (lb): 63 lbs. Printheads: 1 Inks: Dye Based Maximum Lines of Print: 5 Maximum Line Speed (1): 279 m/min (914 ft/min) Environmental Protection: IP55 (IP65 optional) Umbilical Length: 3 m (9.8 ft.) optional 6 m (19.6 ft.) Message Storage Capability: 250 Smart Cartridge™: Included Plug and Play Printhead Modules: Included USB: Included Communications: Ethernet and RS-232 Serial Positive Air / CleanFlow™: Included Display (User Interface): CLARiTY® based 10.4 inch color touchscreen " 0719-178-0039 Union Process, 1S, Attritor, 2 hp Capacity, 300 lbs. " Product Overview: Used Attritor mill, intermittent type attritor, manufactured by Union Process, size 1S, type B, complete with stainless steel, jacketed tank. Tank measures 5"" diameter x 6"" deep, includes stainless steel agitator with paddles. Complete with 3/4 HP, DC drive thru gearbox with unltracon ""screw drive"" vari-speed controls. Previously used to grind ceramic powders. Appears to be in very good condition. Includes spare agitator. Product Features: • One(1) used 1S Union Process Attritor Tank • 8"" inside diameter • 10.5"" deep • Includes front pour spout • Jacketed for cooling • Bottom drain with grate. • Teflon extended piece factory attached • Split aluminum covers • Looks like it is unused General: Manufacturer: Union Process Model Name: Attritor Model Number/MPN: 1S Inventory Number: 0719-178-0039 Series: 960202 Specifications: Aisle: OFF Bay: SITE Weight (lb): 300 lbs. Capacity: 2 hp " 0321-069-0003 Clausing/Colchester, 13, Geared Head Lathe, 13 x 40 in. Capacity, 3 hp, 2230 lbs. " Product Overview: Clausing Colchester geared head engine lathes are the industry standard for conventional lathes because the quality built into every machine translates into real long-term performance in your application. Rugged construction, consistent quality in design and production and the “human engineering” which makes the operator more efficient, all make this lathe a cost-effective investment. Product Features: • Fully-geared headstock with 12 spindle speeds • All headstock gears are hardened and ground • Headstock shafts are splined and turn on anti-friction bearings • Spindle bearings, gears and shafts are lubricated by a forced lubrication system • A broad range of feed and thread selections are available by using three selector levers and 8-position rotary dial • Precision Gamet spindle bearings • Cross slide runs along a dovetail guide • Bed wipers and an apron mounted one-shot lubrication pump • The cast iron apron is totally enclosed and splash bath lubricated • Gap bed with easy-to-remove bed blocks • 40″ center distances • Equipped with chuck guard, full splash guard and lead screw cover • Clutch drive, reverse lead screw with spindle turning for faster thread cutting • Extra wide bed provides accuracy and minimal wear General: Manufacturer: Clausing/colchester Model Name: Geared Head Lathe Model Number/MPN: 13 Inventory Number: 0321-069-0003 Series: 5/0014/07956 Specifications: Aisle: 08B Bay: 3000 Weight (lb): 2230 lbs. Capacity: 13 x 40 in. Capacity: Height of Center: 6 1/2 in. Depth of Center: 40 in. Swing over Bed: 13 in. Swing in Gap: 18.8 in. Width in Front of Faceplate: 4 1/2 in. Swing over Cross Slide: 8.26 in. Bedway Width: 12 ½ in. Headstock: Spindle Bore: 1 1/2 in. Spindle Nose: D1-4 Spindle Nose Taper: 3 M.T. Spindle Speeds: 40 to 2500 rpm (12 Steps) Cross/Top Slide: Travel Cross Slide: 7-1/2 in. Width of Cross Slide: 5-1/2 in. Travel of Top Slide: 3.63 in. Width of Top Slide: 3-1/4 in. Tailstock: Quill Travel: 4.38 in. Quill Diameter: 1.63 in. Quill Taper: 3 M.T. Feeds and Threading: Longitudinal Feed Range: 0.001 to 0.039 in. /rev. Number of Inch Pitches: 35 Range of Inch Pitches: 2 to 56 TPI Number of Metric Pitches: 39 Range of Metric Pitches: 0.2 to 14 mm Number of Diametral Pitches: 18 Range of Diametral Pitches: 8 to 56 DP Number of Module Pitches: 18 Range of Module Pitches: 0.3 to 3.5 MOD Spindle Motor: 3 hp " 0321-024-0015 Varian, 979, Helium Mass Spectrometer Agilent Leak Detector, 195 lbs. " Product Overview: Even with today's complex technology, it is, for all practical purposes, impossible to manufacture a sealed enclosure or system that can be guaranteed leak proof without first being tested. Through the use of modern mass spectrometer leak testing techniques, as implemented by the Varian 979 Helium Leak Detector, leak rates in the 10−9 std cc/sec range can be reliably detected. The Agilet 979 is a wide-range Helium Mass Spectrometer Leak Detector. It is comprised of a turbo-molecular high vacuum pump, spectrometer tube, valve block, Varian Vacuum Technologies’ Platform leak detector electronics, and an operator interface in a stylish, yet rugged housing. Product Features: • Agilent Technologies / Varian • Helium Leak Detector • Fully Re-manufactured • Roughing Pump not included General: Manufacturer: Varian Model Name: Helium Leak Detector Model Number/MPN: 979 Inventory Number: 0321-024-0015 Series: LLB9029 Power Requirements: Power: 115V, 50 Hz | 115V, 60 Hz (20 amps) Specifications: Aisle: 03B Bay: 3600 Weight (lb): 195 lbs. Sensitivity Ranges in Atmospheric-Cc/sec Helium: Std. Sensitivity, 1 Pri. Pump: 10-4 thru 10-9 Std. Sensitivity, 2 Pri. Pumps: 10-1 thru 10-9 High Sensitivity, 1 Pri. Pump: 10-5 thru 10-10 High Sensitivity, 2 Pri. Pumps: 10-2 thru 10-10 Minimum Detectable Leak at 1000 Ppm Ambient Helium: Std. Sensitivity: 5 x 10-10 atm-cc/sec helium High Sensitivity: 5 x 10-11 atm-cc/sec helium Maximum Test-Port Pressure: 1 Primary Pump: 5 torr 2 Primary Pumps: 760 torr Test-Port Connector: NW-25 KF flange (adapter to 1-1/8 in. compression fitting available) Leak Rate Indication: 50-segment log or linear LED bar graph plus numeric readout on screen Leak Rate Units Displayed: atm-cc/sec, mbar-l/sec, torr-l/sec, Pa-m³/sec Test-Cycle Control: Automatic Calibration Routine: Automatic or manual Background Suppression (zeroing): Automatic and Auto-Zero < Zero Changing Ranges: Automatic Protection from Air-Inrush and Power Failure: Automatic Audio Signal: Both threshold and volume can be controlled Remote Analog Leak-Rate Output: Phone jack, 0 to 5V dc Recommended Ambient Operating Temperature: With Rotary-Vane Pump(s): 12 to 40 deg C With Dry Scroll Pump(s): 5 to 40 deg C " https://www.ajvs.com/library/Varian%20979C%20Helium%20Leak%20Detector%20Operations%20Manual.pdf 0221-089-0001 Newport, RS4000, Optical Table, 48 x 144 x 12 in. Capacity, 2020 lbs. " Product Overview: Featuring Six precision tunable dampers, RS4000 optical table tops bring the best passive damping performance to your applications that require a critical level of damping. The 6 dampers are designed to specifically target a majority of the resonances of the table. The result is an ultra quiet tabletop that's ideal for critical applications such as live cell imaging, high resolution imaging, interferometry, experiments with long exposure time and more. • Six precision tunable dampers concentrate damping where it's needed • Honeycomb core for a lighter, stiffer table with better dynamic rigidity • Triple core interface increases point loading capability • Mounting holes individually sealed with conical polymeric cup • Compatible with S-2000A isolators and LabLegs supports Product Features: RS4000 Optical tables use Tuned Mass Damping (TMD) technology to eliminate table resonances. TMD is the most effective method among all known passive damping methods, as it concentrates damping efforts where it's needed at the frequencies of dominant resonance modes. It is widely used in various industries for its efficiency and effectiveness of damping, such as the famous Grand Canyon Skywalk, Taipei 101 Building, and NASA's Ares I rocket. Compared to our top competitor's broadband damping methods which absorbs a moderate amount of vibration energy equally over the broad band, Newport's tuned mass damping method targets at resonances and as a result is much more effective. Our precisely tuned dampers work from as low as 25 Hz and go all the way up to 525 Hz, creating opportunity for optimum damping on larger optical tables, the resonances of which often fall outside of competitor's broadband frequency range. RS4000 Broadband and Tuned Damping Performance: RS4000 Series optical tables are a culmination of many years of experience, innovation and attention to detail leading to unmatched vibration immunity. RS4000 tables feature a 4.8 mm thick optical table skin, a constrained layer core, damped working surface and composite edge finish to provide broadband damping. Six precision tuned dampers are included to selectively eliminate four fundamental structural table modes and their entire harmonics. Originally designed for high end interferometric research, these optical tables are the best choice for extremely sensitive measurements such as live cell imaging, high resolution imaging, interferometry, experiments with long exposure time and so on. The Compliance curve shows the positional motion of the structure for a given excitation force and frequency. The red line is the rigid body line showing how an ideal optical table would perform with no relative motion. The blue line shows the natural frequencies of the optical table and how they deviate from that of a rigid body. Super Rigid Trussed Honeycomb Core Design: Newport's honeycomb core is different than our competitors. Each piece of the corrugated honeycomb steel sheet is emerged in proprietary elastomeric vibration absorbing materials and bonded vertically throughout the height of the optical breadboard or optical table, creating a much stiffer honeycomb core structure. This labor intensive procedure makes sure that Newport's optical breadboard or optical table has the most robust honeycomb structures. Vertically Bonded Triple Core Interface: All Newport tables are vertically bonded along the height of the honeycomb core. Most other manufacturers forego this extra step because of added expense and time required to apply adhesive to each individual core member. Vertical bonding adds constrained layer damping effects into the core, while maximizing the table’s rigidity-to-weight ratio. The trussed core design enables a triple core interface at each honeycomb cell. Whereas open core designs only have two structural members at each interface, the Newport table has three offering a 50% increase in local rigidity. The three sheets are fully bonded for the full table height producing greater stiffness. Individually Sealed Mounting Holes: All of Newport's optical breadboards and tables are with individually sealed mounting holes. Those mounting holes feature 19 mm screw depth and in contrast to some of the other products in the market that has channel for a row of holes or just a polymeric film, Newport's individually sealed holes are more reliable and easier to clean. This is because we believe in the integrity of the product - especially the core. When dust and liquids go into your optical breadboard and table, it may have a long term effect on the damping performance of the product and make the product degrade over time. A good quality breadboard and table lasts long time - tens of years and more. It's a good investment for a product with sealed mounting holes. Precision Grid of Tapped, Countersunk & Deburred Mounting Holes: The 1/4-20 or M6 tapped mounting holes are countersunk and debarred. This ensures easy thread engagement while eliminating contamination problems. The mounting holes are located on a 1 in. or 25 mm grid with standard grid markings for easy and repeatable component placement. Highly Damped Side Panels: Side panels for optical tables are more than just covers. They should contribute to the overall damping performance of the table. Our optical tables use highly damped composite wood as side panels to help eliminate vibrations from the side. Composite wood has a much better damping performance than steel. Steel has a high elasticity and tends to allow vibration or ringing. Materials with low elasticity such as wood tend to dampen vibration and ringing. For example, home stereo speakers are typically enclosed by composite wood to damp the acoustic vibrations. Unique Pressure Bonding Process Ensures Superior Flatness: Metrology quality steel assembly platens are used to ensure the superior flatness of our optical tables. The platen supports the top surface of the table during the assembly and bonding process and imprints the top surface with the same flatness characteristics. Our platens are the largest and flattest in the industry. We use gravity pressure bonding to apply constant pressure across the optical table during the bonding process ensuring that the top surface conforms to the platen flatness. Optical Table Support Options: We offer three types of supports for our optical tables. S-2000A vibration isolators with automatic re-leveling provide industry leading vibration isolation performance, and include an integrated, mechanical height adjustment system to allow improved table leveling, height control and compensation for non-level floors. SL Series pneumatic vibration isolators offer vibration isolation at a very affordable price when automatic re-leveling is not required. The isolators remove floor vibrations in the 10 Hz to 50 Hz range and support a wide variety of less rigorous research and production applications. RL Series non-isolating rigid support legs offer rigid high load support where vibration isolation is not required. Custom Optical Table Design Options: Newport has a dedicated custom design team for your custom needs. This team has been working with various types of materials, shapes (see doubled table tops), structures, hole patterns (and many more) for over 40 years, and has served customers across the world in research, aerospace, semiconductor and medical related fields. Newport is committed to providing: The most accurate and timely quoting response; The most professional communications of custom design review and changes; The optimum turnaround time and the highest quality end product. Contact Newport today for your custom needs. General: Manufacturer: Newport Model Name: Optical Table Model Number/MPN: RS4000 Inventory Number: 0221-089-0001 Specifications: Aisle: 11B Bay: 2200 Weight (lb): 2020 lbs. Capacity: 48 x 144 x 12 in. " 0221-050-0148 Starrett, HE400, Horizontal Bench top Optical Comparator, 15 in. Capacity, 550 lbs. " Product Overview: The HE400 Horizontal Bench top Optical Comparator offers a 16"" screen, 10"" fast traverse X-axis travel, 4” Y-axis travel, quick change bayonet fitting lenses, Q-axis digital protractor with angular measurements to 1' resolution and your choice of powerful Quadra-Chek or MetLogix software control systems. A time tested, cost effective, solution for non-contact measurement. They are simple to use, yet have great capacity and performance to satisfy an exceptionally wide range of dimensional inspection applications and complex measuring requirements. At the heart of these systems are precision optics, superb lighting and a highly accurate work stage which combine to ensure bright, sharp images and exceptional accuracy. Horizontal models work well with parts that need to be fixture, held in a vice, or on centers. Product Features: • Redesigned for improved performance • All metal construction • 16"" diameter screen with overlay clips • Digital protractor for accurate angular measurements (1 minute resolutions) via Q axis on readout • Precision work stage with 18.75 x 4.74"" top plate with machined slot for easy fixturing • 5.4 lb load capacity and 55lb maximum capacity • 10"" horizontal travel by manual fine adjustment with quick release mechanism on X-axis • 4"" vertical travel • 1-1/8"" focus travel • LED profile illumination • LED fiber optic surface illumination • Fully retractable flexible fiber optic surface illumination • Single bayonet-style interchangeable lens mount (10 x lens included) • Collimating condenser with yellow/green filter and provision to mount further accessories • Measurement by means of a linear encoder (glass scale) with .5μ on both X and Y axes • Fine adjustment on all axes General: Manufacturer: Starrett Model Name: Horizontal Bench top Optical Comparator Model Number/MPN: HE400 Inventory Number: 0221-050-0148 Series: 41274 Specifications: Aisle: 09A Bay: 3300 Weight (lb): 550 lbs. Capacity: 15 in. System Type: Bench Top Part View Orientation: Horizontal Screen Diameter (in): 16"" Screen Diameter (mm): 400 X-Y Measuring Range (in): 10"" x 4"" X-Y Measuring Range (mm): 250 x 100 Linear Glass Scale Encoder on X Y Axis: Standard Focus Range (in): 1.125"" Focus Range (mm): 30 Work Stage (in): 18.75"" x 4.75"" Work Stage (mm): 475 x 120 Load Capacity with Negligible Deflection (lbs): 15 Load Capacity Maximum (lbs): 55 Angular Measurement Resolution: 1 Minute Profile Illumination: Standard Surface Illumination: Standard Quick Change Lens Mount (Lenses Not Included): Single Collimating Condenser with Yellow/Green Filter: Standard Control System / Software: QC100/200, M2 Lenses: 10X, 20X, 25X, 31.25X, 50X, 100X Display: QC DRO or 15.6"" Touch screen PC " 0517-133-0011 Peltesman, MIGL-33, Semiautomatic Molding Machine, 12 x 8 x 16 in. Capacity, 4000 lbs. " Product Overview: Semiautomatic Low Pressure Molding Machine for molding net shape ceramic, metal and wax parts for experimental or small production, using thermoplastic or thermosetting binders. Product Features: • Production rate up to 70 cycles per hour, depending on the complexity of a mold. • Stainless steel tank, tank lid, mixer blades and feeder pipe. • Tank volume 0.8 gallons (3.5 liters). • Double blade planetary mixer with variable speed of rotation in the tank. • Pneumatic clamping cylinder. • 1/4 HP mixer motor. • Max. molding air pressure up to 70 psi (5 kg/cm.sq.). • Molding temperature up to 300°F (150°C), independently controlled in the tank, in the feeder pipe and at the orifice with three microprocessor temperature controllers with digital display. • Vacuum pump for deairing during mixing. • Average energy consumption 2 kW. • Power: 110/120 VAC, 50/60 Hz, single phase. • Overall dimensions 25""L x 24""D x 56""H; (635 x 610 x 1425 mm). General: Manufacturer: Peltesman Model Name: Semiautomatic Molding Machine Model Number/MPN: MIGL-33 Inventory Number: 0517-133-0011 Series: 0101 Specifications: Aisle: OFF Bay: SITE Weight (lb): 4000 lbs. Capacity: 12 x 8 x 16 in. " 1220-026-0018 Abb, IRC5 M2004, Robot Control, 580 lbs. " Product Overview: The ABB IRC5 M2004 Controller gives our robots the ability to perform their tasks in a highly efficient manner. Based on advanced dynamic modeling, the ABB IRC5 M2004 Controller automatically optimizes the performance of the robot by reducing cycle times (QuickMove ®) and providing precise path accuracy (TrueMove ®). Thanks to ABB IRC5 M2004 Controllers technology, a robot’s motion is predictable and its performance high, with no tuning required by the programmer. Product Features: ABB IRC5 M2004 Single Cabinet Controller: • Designed for high IP protection and full expandability • Provides a protected environment for axillary equipment in the robot system • Capable of control of up to four robots in a MultiMove ® setup. Just add a compact drive module to each additional robot • MultiMove ® opens up previously unthinkable operations, thanks to the perfect coordination of complex motion patterns • At iGAM, we’re committed to not only keep your robots and automation lines running, but running safely and in compliance with all regulations. Find additional Robot Parts & Accessories here, from ABB and other manufacturers. General: Manufacturer: Abb Model Name: Robot Control Model Number/MPN: IRC5 M2004 Inventory Number: 1220-026-0018 Series: 66-51392 Specifications: Aisle: 04A Bay: 1300 Weight (lb): 580 lbs. " https://library.e.abb.com/public/e6617595547fc6c2c1257cc5004451bd/Operating%20manual_Trouble%20shooting_3HAC020738-001_revK_en.pdf 0720-088-0002 Wright Machine Tools, TW-3, Automatic Dc Tip Welder / Induction Annealer, 230V, 1-Phase, 50 Hz/60 Hz, 6975 lbs. " Product Overview: An Advanced computer “PLC” handles machine control. The DC weld head reduces sensitivity to incoming voltage fluctuations and allows welding on plate thickness down to 0.030"" with tips down to 0.050"" wide. The Annealing unit is a compact device that is manufactured using solid-state technology; each has an embedded microprocessor that guarantees stable power output as well as optimum operating frequency. The microprocessor also performs monitoring and diagnostic functions to inform the user of device status. The Talon TW-3 tipper, makes use of innovative preformed Stellite® tipping technology, making the tipping process easier and more affordable than ever. Our unique Weld System turns slag into an advantage by keeping it in the weld zone. This not only strengthens the weld but allows for full annealing of the slag material. In addition to being the fastest tipping and annealing machine on the market, the TW-3 cuts grinding times significantly. The triangular design of the tip has the top and face angles already in place. With the TW-3's ability to accurately place the tips centered on the saw, side-grinding time is also reduced. All of this adds up to added Stellite® tip life, lower abrasive wheel use, and saving time. Product Features: • Low Stellite® Cost • Preformed Tips • Power Weld Forging • Tip Alignment System • Anneal With Learn Mode • Swing Away Clamp • Water Cooled System • Compact Size • Operator Interface • Advanced PLC Control General: Manufacturer: Wright Machine Tools Model Name: Automatic Dc Tip Welder / Induction Annealer Model Number/MPN: TW-3 Inventory Number: 0720-088-0002 Series: 071002TW3 Power Requirements: Power: 230V, 1-Phase, 50 Hz/60 Hz Air: 2 cfm and 80 psi Power Consumption: 2.5 kw Specifications: Aisle: 03A Bay: 1400 Weight (lb): 6975 lbs. Bands: 4 to 16 in. Circle Saw Size: 6 to 36 in. Crate Size: 67 x 48 x 64 in. " https://static1.squarespace.com/static/57c62204197aea3e7a3b7d6e/t/57ee914bff7c50657d59bba3/1475252566773/TW-3+Manual.pdf 1020-076-0002 Yes Tech, F1, Optical Inspection Machine, 2290 lbs. " Product Overview: YESTech’s advanced Thin Camera™ technology offers high-speed PCB inspection with exceptional defect coverage. With up to two top-down viewing cameras and four side viewing cameras, the F1-Series inspects solder joints and verifies correct part assembly enabling users to improve quality and increase throughput. Programming the F1-Series is fast and intuitive. Operators typically take less than 30 minutes to create a complete inspection program including solder inspection. The F1-Series utilizes a standard package library to simplify training and insure program portability across manufacturing lines. Newly available image processing technology integrates several techniques, including color, normalized correlation and rule-based algorithms, to provide complete inspection coverage with an extremely low false failure rate. Configurable for all line positions, the F1-Series is equally effective for paste, pre / postreflow or final assembly inspection. Off-line programming maximizes machine utilization and realtime SPC monitoring provides a valuable yield enhancement solution. Automated Inspection for: • Solder defects • Lead defects • Component presence and position • Correct part / polarity • Through-hole parts • Paste Product Features: • Quick Set-up • High Speed • High Defect Coverage • Low False Failure Rate • Best Price Performance General: Manufacturer: Yes Tech Model Name: Optical Inspection Machine Model Number/MPN: F1 Inventory Number: 1020-076-0002 Series: V30512301 Specifications: Aisle: 10B Bay: 3000 Weight (lb): 2290 lbs. YTV-F1: Multi-function system with top-down viewing camera Inspection Capabilities: Throughput: Up to 5 sq. in./ sec. > 250,000 components per hour Maximum Board Size: 22 x 20 in. (560mm x 510mm) Clearance: 2 in. (50 mm) top and bottom Minimum Component Size: 0201; 01005 with high magnification option Defects Detected: Component: position, missing, wrong, polarity, skew, tombstone Lead: bent, lifted, bridging Solder: open, insufficient, short, solder balls Software: Algorithms: Normalized correlation, OCV, OCR, barcode recognition and rule-based CAD Input: Pick and place data, CAD x-y data CAD Translation Package: Excel, Circuitcam, Unicam, CIMBridge, Fabmaster Programming Skill Level: Technician or operator Operating System: Windows XP Professional Off-line Software: Optional software for rework and off-line programming Outputs: Real-time SPC outputs reporting first pass yield, defect byclassification, reference designator and part number with remote monitoring. Hardware: Material Handling: USB 2, SMEMA, dual direction auto width conveyor Lighting: LED top light, proprietary bi-color multiangle LED lighting Imager: Multiple Thin Camera™ mega-pixel color cameras Resolution 1280 x 1024; 25 micron pixel size Board Clamps: Optional High Magnification: Optional 12 micron high magnification camera Bottom Side Camera: Optional for bottom side bar codes Facilities: Power: 110V ac ( 220 optional ) 50/60 Hz, 15 amps Air Input: 30 psi min., 1/4 air hose Footprint: 55 x 57 x 50 in. (1400 x 1450 x 1270 mm) Machine Installation: < 1 hour " 1020-076-0001 Yes Tech, F1, Optical Inspection Machine, 2260 lbs. " Product Overview: YESTech’s advanced Thin Camera™ technology offers high-speed PCB inspection with exceptional defect coverage. With up to two top-down viewing cameras and four side viewing cameras, the F1-Series inspects solder joints and verifies correct part assembly enabling users to improve quality and increase throughput. Programming the F1-Series is fast and intuitive. Operators typically take less than 30 minutes to create a complete inspection program including solder inspection. The F1-Series utilizes a standard package library to simplify training and insure program portability across manufacturing lines. Newly available image processing technology integrates several techniques, including color, normalized correlation and rule-based algorithms, to provide complete inspection coverage with an extremely low false failure rate. Configurable for all line positions, the F1-Series is equally effective for paste, pre / postreflow or final assembly inspection. Off-line programming maximizes machine utilization and realtime SPC monitoring provides a valuable yield enhancement solution. Automated Inspection for: • Solder defects • Lead defects • Component presence and position • Correct part / polarity • Through-hole parts • Paste Product Features: • Quick Set-up • High Speed • High Defect Coverage • Low False Failure Rate • Best Price Performance General: Manufacturer: Yes Tech Model Name: Optical Inspection Machine Model Number/MPN: F1 Inventory Number: 1020-076-0001 Series: V30601319 Specifications: Aisle: 10B Bay: 3000 Weight (lb): 2260 lbs. YTV-F1: Multi-function system with top-down viewing camera Inspection Capabilities: Throughput: Up to 5 sq. in./ sec. > 250,000 components per hour Maximum Board Size: 22 x 20 in. (560mm x 510mm) Clearance: 2 in. (50 mm) top and bottom Minimum Component Size: 0201; 01005 with high magnification option Defects Detected: Component: position, missing, wrong, polarity, skew, tombstone Lead: bent, lifted, bridging Solder: open, insufficient, short, solder balls Software: Algorithms: Normalized correlation, OCV, OCR, barcode recognition and rule-based CAD Input: Pick and place data, CAD x-y data CAD Translation Package: Excel, Circuitcam, Unicam, CIMBridge, Fabmaster Programming Skill Level: Technician or operator Operating System: Windows XP Professional Off-line Software: Optional software for rework and off-line programming Outputs: Real-time SPC outputs reporting first pass yield, defect byclassification, reference designator and part number with remote monitoring. Hardware: Material Handling: USB 2, SMEMA, dual direction auto width conveyor Lighting: LED top light, proprietary bi-color multiangle LED lighting Imager: Multiple Thin Camera™ mega-pixel color cameras Resolution 1280 x 1024; 25 micron pixel size Board Clamps: Optional High Magnification: Optional 12 micron high magnification camera Bottom Side Camera: Optional for bottom side bar codes Facilities: Power: 110V ac ( 220 optional ) 50/60 Hz, 15 amps Air Input: 30 psi min., 1/4 air hose Footprint: 55 x 57 x 50 in. (1400 x 1450 x 1270 mm) Machine Installation: < 1 hour " 0321-098-0007 Carver, 3970, Bench Top Manual Molding Press, Vertical Orientation, 830 lbs. " Product Overview: Thirty ton, Manual, four-column, Hydraulic press. Has two-speed pump, first stage for rapid closing and second for pressing mode. Fully guided moving platen assures parallelism over 12"" x 12"" surface. Daylight opening is adjustable up to 17"". Easy-to-read dual scale analog gauge, reading in pounds force and metric tons. Product Features: • Manually operated • Clamping force 30 tons • Adjustable Daylight 1 to 17 in. (Factory set at 4 1/2 in.) • Stroke 6” • Four (4) fully threaded columns • 12”x 12” work area • 0-60,000 lb Analog pressure gauge, reading in 500 lb increments (digital gauge also available) • Light gray safety shield • Dark gray frame • Dimensions: 24”L-R x 27”F-B x 45”H (un-crated) General: Manufacturer: Carver Model Name: Bench Top Manual Molding Press Model Number/MPN: 3970 Inventory Number: 0321-098-0007 Series: 3970-166 Specifications: Aisle: 04B Bay: 3500 Weight (lb): 830 lbs. Product Category: Molding Machines Machine Type: Compression Molding Actuation: Hydraulic, Manual Orientation: Vertical " 0620-161-0001 Tschudin, HTG 442, Hydraulic Grinding Machine, 20 mm Sleeve Stroke, 5.5 kW, 5985 lbs. " Product Overview: The machine is currently in used condition. In case of order, we change all wear parts (incl. the spindle). Also we change the old marposs control to the new 2-axis positioning control. On customer request the machine will get new varnishing. Product Features: Oblique Diving Marposs Diameter Measure System Marposs Positionor Trueing by Copying Lubricating Tank with Pump General: Manufacturer: Tschudin Model Name: Hydraulic Grinding Machine Model Number/MPN: HTG 442 Inventory Number: 0620-161-0001 Series: 77 156 Make Year: 1977 Specifications: Aisle: 06B Bay: 1500 Weight (lb): 5985 lbs. Workpiece headstock: MK4 Tailstock: MK3 Standard Centre Height: 100 mm Centre Distance: 480 mm Grinding Length: 420 mm Dimensions of grinding wheel: 500 x 80 x 203,2 mm Feed: X- Achse (Schrittmotor) Control: Schrittmotor Space Required for the Machine: 2670 x 2250 x 1900 mm Strokes: x = 420 mm, y = 45 mm Table Orientation : + / - 9 deg Grinding Wheel Diameter: 500 mm Maxi Width: 80 mm Wheel Head Power: 5,5 kw Work Head Cone: CM 4 Work Head Orientation: 360 deg Turning Speed: 65-500 [r/min] Counter Headstock Sleeve Cone: CM3 Sleeve Stroke: 20 mm Sizes: 2700 x 1800 x 1900 mm " 0620-161-0002 Tschudin, HTG 442, Hydraulic Grinding Machine, 20 mm Sleeve Stroke,5.5 kW, 6170 lbs. " Product Overview: The machine is currently in used condition. In case of order, we change all wear parts (incl. the spindle). Also we change the old marposs control to the new 2-axis positioning control. On customer request the machine will get new varnishing. Product Features: Oblique Diving Marposs Diameter Measure System Marposs Positionor Trueing by Copying Lubricating Tank with Pump General: Manufacturer: Tschudin Model Name: Hydraulic Grinding Machine Model Number/MPN: HTG 442 Inventory Number: 0620-161-0002 Series: 81 283 Make Year: 1981 Specifications: Aisle: 06A Bay: 1800 Weight (lb): 6170 lbs. Workpiece headstock: MK4 Tailstock: MK3 Standard Centre Height: 100 mm Centre Distance: 480 mm Grinding Length: 420 mm Dimensions of grinding wheel: 500 x 80 x 203,2 mm Feed: X- Achse (Schrittmotor) Control: Schrittmotor Space Required for the Machine: 2670 x 2250 x 1900 mm Strokes: x = 420 mm, y = 45 mm Table Orientation : + / - 9 deg Grinding Wheel Diameter: 500 mm Maxi Width: 80 mm Wheel Head Power: 5,5 kw Work Head Cone: CM 4 Work Head Orientation: 360 deg Turning Speed: 65-500 [r/min] Counter Headstock Sleeve Cone: CM3 Sleeve Stroke: 20 mm Sizes: 2700 x 1800 x 1900 mm " 1220-026-0031 Abb, IRC5 M2004, Robot Control, 555 lbs. " Product Overview: The ABB IRC5 M2004 Controller gives our robots the ability to perform their tasks in a highly efficient manner. Based on advanced dynamic modeling, the ABB IRC5 M2004 Controller automatically optimizes the performance of the robot by reducing cycle times (QuickMove ®) and providing precise path accuracy (TrueMove ®). Thanks to ABB IRC5 M2004 Controllers technology, a robot’s motion is predictable and its performance high, with no tuning required by the programmer. Product Features: ABB IRC5 M2004 Single Cabinet Controller: • Designed for high IP protection and full expandability • Provides a protected environment for axillary equipment in the robot system • Capable of control of up to four robots in a MultiMove ® setup. Just add a compact drive module to each additional robot • MultiMove ® opens up previously unthinkable operations, thanks to the perfect coordination of complex motion patterns • At iGAM, we’re committed to not only keep your robots and automation lines running, but running safely and in compliance with all regulations. Find additional Robot Parts & Accessories here, from ABB and other manufacturers. General: Manufacturer: Abb Model Name: Robot Control Model Number/MPN: IRC5 M2004 Inventory Number: 1220-026-0031 Series: 66-51271 Make Year: 2005 Specifications: Aisle: 04A Bay: 1300 Weight (lb): 555 lbs. " 1020-183-0003 Big Joe, PDC-40-106, Walk Behind Forklift, 4000 Capacity, 7140 lbs. " Product Overview: The “Walkie” alternative to a sit-down forklift. Our family of counterbalanced walk behind trucks can do the job of a rider for less. Since these trucks do not have to straddle loads they can easily handle a wide range of load sizes and load or unload trailers. Available in a wide variety of configurations our counterbalanced walk behind lift trucks can be specifically tailored to meet the needs of your application. If you’re looking for an alternative to a sit-down forklift your solution is here. Product Features: • 2,500 to 4,000 lb. Capacity depending on vehicle configuration. • 24volt electrical power with Curtis transistor control. • A wide variety of vehicle options to meet your specific application needs. • Chrome plated lift cylinder with pressure compensation lowering valves. • Control arm coupled driveline provides intuitive and direct operator control. • Ergonomic handle with reversing switch, horn and wrap around hand guard. • Premium steel frame construction protects components and reduces maintenance. • Premium steel mast construction provides extended service life and load stability. • Shaft type forks provide for easy adjustment. General: Manufacturer: Big Joe Model Name: Walk Behind Forklift Model Number/MPN: PDC-40-106 Inventory Number: 1020-183-0003 Series: 381942 Make Year: 2008 Specifications: Aisle: 11A Bay: 2200 Weight (lb): 7140 lbs. Capacity: 4000# Capacity at 24 in. Load Centre: 4000 Cl Load wheel to Cl Drive wheel WB: 55.3 Col Height B: 72 Collapsed Height: Based on configuration and max. lift height Ext Height C: 123 Fork Dimensions: A wide variety of options available Free Lift Height: 12 Lift Height A: 106 Max Lift Height: Masts available from 60 to 194 in. Overall Width D: 36 Power Head Length E: 73.30 Turn Radius F: 65.7 Engine Drivetrain: Capacity: 2,500 lbs. to 4,000 lbs. and 24 in. load center Power: 24 volt electric with Curtis transistor control Vehicle Type: Walk behind counterbalanced forklift Operational: Battery Capacity: 200 Ah / 340 Ah/ 510 Ah available Battery: 24V and 510 Ah (1042 lbs.) Charger: External required Charger: 24V and 75 Amp(90 lbs.) " 1220-026-0027 Abb, IRC5 M2004, Robot Control, 655 lbs. " Product Overview: The ABB IRC5 M2004 Controller gives our robots the ability to perform their tasks in a highly efficient manner. Based on advanced dynamic modeling, the ABB IRC5 M2004 Controller automatically optimizes the performance of the robot by reducing cycle times (QuickMove ®) and providing precise path accuracy (TrueMove ®). Thanks to ABB IRC5 M2004 Controllers technology, a robot’s motion is predictable and its performance high, with no tuning required by the programmer. Product Features: ABB IRC5 M2004 Single Cabinet Controller: • Designed for high IP protection and full expandability • Provides a protected environment for axillary equipment in the robot system • Capable of control of up to four robots in a MultiMove ® setup. Just add a compact drive module to each additional robot • MultiMove ® opens up previously unthinkable operations, thanks to the perfect coordination of complex motion patterns • At iGAM, we’re committed to not only keep your robots and automation lines running, but running safely and in compliance with all regulations. Find additional Robot Parts & Accessories here, from ABB and other manufacturers. General: Manufacturer: Abb Model Name: Robot Control Model Number/MPN: IRC5 M2004 Inventory Number: 1220-026-0027 Series: 66-51384 Make Year: 2005 Specifications: Aisle: NPS Bay: Q008 Weight (lb): 655 lbs. " 1220-026-0021 Abb, IRC5 M2004, Robot Control, 615 lbs. " Product Overview: The ABB IRC5 M2004 Controller gives our robots the ability to perform their tasks in a highly efficient manner. Based on advanced dynamic modeling, the ABB IRC5 M2004 Controller automatically optimizes the performance of the robot by reducing cycle times (QuickMove ®) and providing precise path accuracy (TrueMove ®). Thanks to ABB IRC5 M2004 Controllers technology, a robot’s motion is predictable and its performance high, with no tuning required by the programmer. Product Features: ABB IRC5 M2004 Single Cabinet Controller: • Designed for high IP protection and full expandability • Provides a protected environment for axillary equipment in the robot system • Capable of control of up to four robots in a MultiMove ® setup. Just add a compact drive module to each additional robot • MultiMove ® opens up previously unthinkable operations, thanks to the perfect coordination of complex motion patterns • At iGAM, we’re committed to not only keep your robots and automation lines running, but running safely and in compliance with all regulations. Find additional Robot Parts & Accessories here, from ABB and other manufacturers. General: Manufacturer: Abb Model Name: Robot Control Model Number/MPN: IRC5 M2004 Inventory Number: 1220-026-0021 Series: 66-51273 Make Year: 2005 Specifications: Aisle: NPS Bay: Q008 Weight (lb): 615 lbs. " 0121-033-0023 Tri Pack, HT-1, Heat Shrink Tunnel, 5 x 36 x 10 in. Capacity, 3 ft. Tunnel Length, 220V, 3 Phase, 30A, 405 lbs. " Product Overview: TriPack HT-1 Convection Heat Tunnel are excellent shrink tunnel solutions for basic shrink label applications, tamper evident banding, and moisture sensitive products. Compact and mobile in design, this tunnel series is great for versatile contract packaging needs or tight footprint requirements. Expect the highest level of heat and air flow control with HT Series tunnels. Product Features: • Digital temperature read out with adjustable temperature settings • Powered up/ down controls • Cantilever/ conveyor through tunnel design • Conveyor “lock-in” mounting brackets • Extruded aluminium frame with adjustable feet • Digital air flow read out with adjustable air flow settings • E-stop push-button safety feature • Independent and adjustable baffles for air flow direction/ control • Control wiring/ e-stop auto-up safety feature General: Manufacturer: Tri Pack Model Name: Heat Shrink Tunnel Model Number: HT-1 Inventory Number: 0121-033-0023 Series: 6424 Specifications: Tunnel Length: 3 ft. Tunnel Opening: 5.125 x 10.75 in. Max Elevation: 44 in. Elevation Travel: 10 in. Power: 220V, 3 ph, 30 amps Temperature Range: Up to 500 Degrees F Capacity: 5 x 36 x 10 in. Weight (lb): 405 lbs. Bay: 3400 Aisle: 09A " 0121-081-0003 Hyster, S70FT, Propane Forklift, 3800# Capacity, PSI 2.4L/Kubota 2.5L Engine, 8260 lbs. " Product Overview: A versatile lift truck designed for indoor use, this truck is ideally suited for a wide variety of applications such as industrial and commercial machinery, fabricated metal products and motor freight transportation. Product Features: • S40-70FT series choice of 3 high output engines, 2 performance transmissions, 2 hydraulic controls and 3 cooling system options allows you to customize your truck to optimize the productivity in your application • Approximately 70% of industrial lift truck downtime results from problems with the powertrain, electrical system, cooling system or hydraulic system. With the S40-70FT, many of these mechanical issues become a thing of the past as design advances have reduced downtime by up to 30% • Our Auto Deceleration System extends brake life by up to 60% by automatically slowing the truck when the accelerator pedal is released • Controlled power reversal virtually eliminates tire spin, increasing tire life by up to 50%. This feature is programmable to match the needs and experience of the driver • A choice of 3 aluminium core radiators, each with significant design and component improvements, provides the industry’s best cooling capacity – a key factor to increasing uptime and the economic life of your trucks General: Manufacturer: Hyster Model Name: Propane Forklift Model Number: S70FT Inventory Number: 0121-081-0003 Series: F187V17534J Make Year: 2011 Specifications: Load Capacity: 7000 lbs. Engine: PSI 2.4L, Kubota 2.5L Transmission: Electronically Controlled Powershift 1 Speed, DuraMatch Electronic 1 Speed Maximum Travel Speed (MPH): 11.2 Maximum Lift Speed (ft/min): 110 Capacity: 3800# Weight (lb): 8260 lbs. Bay: 1500 Aisle: 11B " 0121-108-0001 Miller, AEROWAVE, TIG Welder, 300A Capacity, 525 lbs. " Product Overview: The Miller Aerowave was an advanced hybrid version of it's predecessor the Syncrowave 375. This machines offers a massive 375 amps on the top end at an excellent duty cycle, along with precision control on the lower end for the welding thin materials. This second hand Miller TIG Welder is not only a rare and sort after model with a lot of added features, but is in excellent condition for a second hand machine. Product Features: • Advanced Squarewave technology eliminates the need for continuous HF - and uses it only to start the arc. Computer friendly • Full Feature Module (Upslope/Downslope, Preflow-Postflow, Spot timer, Pulser) • Duty cycle 60% @ 300A Current range 1-375 Amps • AC Waveform Type Advanced Squarewave • AC Balance Control • AC Frequency Control • AC Independent Amp Control • Lift Arc TIG Start available (No HF interference) • Max Pulse Frequency AC = 500 Hz • Weld Sequence Control • 2 touch and 4 touch trigger Control • Mains supply 220/380/440/520 3 phase • Digital Meters, Digital Parameter Presets General: Manufacturer: Miller Model Name: TIG Welder Model Number: AEROWAVE Inventory Number: 0121-108-0001 Series: KH402362 Make Year: 1997 Specifications: Capacity: 300A Weight (lb): 525 lbs. Bay: 1900 Aisle: 03B " https://www.millerwelds.com/files/owners-manuals/O319H_MIL.pdf 0220-119-0006 Cincinnati, 220-8, Centerless Grinder, 12 in. Grinding Wheel Hole Diameter, 10655 lbs. " Product Overview: The Cincinnati 220-8 centerless grinder is an excellent choice for high precision and high production grinding applications. With a footprint not much larger than the #2OM machine, the 220-8 has drastically more mass and static stiffness. This allows for heavier stock removal and higher precision grinding. The 220-8 can also accommodate larger diameter and longer parts. Product Features: • Long functional life • Easy operation • Sturdy construction Common Applications: • Heavy Stock Removal Hand Feed Infeed Grinding • Multiple Part Infeed Grinding • Thrufeed Shaft Grinding General: Manufacturer: Cincinnati Model Name: Centerless Grinder Model Number: 220-8 Inventory Number: 0220-119-0006 Series: 2M8H5S-8 Specifications: Diameter Capacity, Optimal: 0.040 to 2.5 in. Diameter Capacity, Maximum: Up to 4.75 in. Grinding Wheel Diameter, Minimum: 17.5 in. Grinding Wheel Diameter, Maximum: 20 or 24 in. Grinding Wheel Width, Maximum: 8 in. standard, up to 10 in. Grinding Wheel Hole Diameter: 12 in. Grinding Wheel Motor: 15hp standard, up to 40hp Grinding Wheel Speed, Maximum: 10,500 SFPM Regulating Wheel Diameter, Minimum: 9.5 in. Regulating Wheel Diameter, Maximum: 14″ Regulating Wheel, Maximum: 8 in. Regulating Wheel Hole Diameter: 5 in. Regulating Wheel Speeds, Range: 0 to 300 rpm Regulating Wheel Motor: 1-1/2 hp Static Stiffness: 425,000 lbs. Machine Footprint, Approximately: 10 x 6 x 8 ft. Weight (lb): 10655 lbs. Bay: 2400 Aisle: 05B " 0221-168-0001 Eaton, MDS620, Circuit Breaker, Bolt-On Mount Type, 3 Pole, 3 Phase, 2000 Amps Capacity, 125 lbs. " Product Overview: Eaton's Magnum DS Low Voltage Power Circuit Breakers offer the highest ANSI interrupting and withstand ratings in the industry in the smallest physical size and are the most easily maintained ANSI breakers on the market. Magnum SB are insulated-case power circuit breakers designed for the performance and economic requirements of UL 891. Both are ideal for switchgear and switchboards, providing excellent safety, flexibility, and a high level of performance. Product Features: • 600 Vac • AC Power Interrupting Ratings: • 65 kA @ 635 Volts • 65 kA @ 508 Volts • 65 kA @ 254 Volts Trip Unit: • Digitrip 520 • Trip Unit • 5LSIG • LSIG Functions – (Long Time, Short Time, Instantaneous, Ground Fault) General: Manufacturer: Eaton Model Name: Circuit Breaker Model Number: MDS620 Inventory Number: 0221-168-0001 Make Year: 2017 Specifications: Amperage: 2000 Family: Magnum DS Trip Functions: LI Poles: 3 Type: MDS AIC: 65kA@480V Mount Type: Bolt-On Capacity: 2000 Amps Weight (lb): 125 lbs. Bay: 3300 Aisle: 02A " 0720-017-0014 Carver, 3889, Platen Press, 6 x 6 in. Platen Size, 6 X 6 in. BED Capacity, 375 lbs. " Product Overview: Carver Auto Series Plus automatic laboratory presses feature a large 7” color touch screen operator interface, enhanced platen temperature control with auto-tuning, ramp heating capability, storage of up to 250 recipes and real-time trending of force and temperature. Optional features include seven day timer for auto platen heat-up, data logging for cycle parameters, and access to logged data through Wi-Fi. 48 ton models include a wrap-around floor stand. Auto Series Plus press models are available with 15 to 48 tons of clamping force and 6"" x 6"" to 19” x 19” platens. These benchtop presses are used in quality control and research and development for test sample preparations, destructive testing, molding, laminating and fluid extraction. See below table for press specifications. Product Features: • Access Door • Clear, impact resistant polycarbonate door permits observation and serves a safety shield to protect the operator • Threaded Rods • Permits adjustment of Daylight opening • Heated Platens • With digitally controlled cartridge heaters (optional) • Proximity Switch • For adjustable slow close position • Heavy Duty Bolsters • Provide maximum rigidity • Hydraulic Cylinder • Delivers up to 48 tons of force • Unitized Base • Makes installation and set-up easy • Full Touch Screen Interface • For precise, programmed process control • Dual Operator Buttons • With ""anti-tie-down"" feature requires two-handed operation for operator safety • Hydraulic Power Unit • Completely self-contained, electrically operated General: Manufacturer: Carver Model Name: Platen Press Model Number: 3889 Inventory Number: 0720-017-0014 Series: 3889-1 Specifications: Model: Auto C-PL,H Max. Clamp Force, Tons (lbs.): 15 (30,000) Heated Platens: Yes Platen Size: 6 x 6 in. Ram Stroke: 6 in. Daylight Opening: 0 to 13 in. Overall Size (W x D x H): 42.50 x 24 x 45 in. Voltage Supply: 115/230, 1 phase Capacity: 6 X 6 in. BED Weight (lb): 375 lbs. Bay: 3300 Aisle: 04A " 0920-035-0006 Durant, MSC-600-SR, Scrap Cutter, 102 SPM Speed, 5 HP Motor, 3.7 kW, 24 in. OPENING Capacity, 2300 lbs. " Product Overview: Our scrap cutters can give you twice the life you would get with any shearing-cut (reciprocating-cut) machine. And we have proven it in the field... hundreds of times. It is because these units let you perform high accuracy cutting of thickness from .002"" without a clearance adjustment. It is because regular greasing is the only maintenance these machines require. It is because these machines typically run two to three years between blade sharpening. But durability is just where the advantages of these patented waving-cut machines begin. They are also easy to use and have been designed so they will not damage presses, dies or feed gears under any circumstances. They can be set up to suit your operation with the motor mounted on either the top or bottom of the cutting frame. Product Features: • Tool life is several times as long as that for shearing-cut (reciprocating cut) machines • Greasing is the only maintenance requirement • The machines are designed on many years experience. Various improvement suggested by users have been introduced for higher efficiency and convenience in practical use • These patented waving-cut machines are simple in construction, yet very durable • High-accuracy cutting of thickness from 0.002"" is ensured without tool clearance adjustment • It is not necessary for the machines to be synchronized with presses and require little floor space • There is no possibility for presses, dies or feed gears to be damaged by the machines • Heavy duty machines with no equal in the metal stamping industry General: Manufacturer: Durant Model Name: Scrap Cutter Model Number: MSC-600-SR Inventory Number: 0920-035-0006 Specifications: Maximum Thickness: .160 Maximum Width: 20 in. Reduction Gear Ratio: 1:17 Speed (SPM): 102 Motor (HP): 5 Capacity: 24 in. OPENING Weight (lb): 2300 lbs. Bay: 3000 Aisle: 04B " 0920-035-0007 Durant, MSC-600-SR, Scrap Cutter, 102 SPM Speed, 5 HP Motor, 3.7 kW, 24 in. OPENING Capacity, 2305 lbs. " Product Overview: Our scrap cutters can give you twice the life you would get with any shearing-cut (reciprocating-cut) machine. And we have proven it in the field... hundreds of times. It is because these units let you perform high accuracy cutting of thickness from .002"" without a clearance adjustment. It is because regular greasing is the only maintenance these machines require. It is because these machines typically run two to three years between blade sharpening. But durability is just where the advantages of these patented waving-cut machines begin. They are also easy to use and have been designed so they will not damage presses, dies or feed gears under any circumstances. They can be set up to suit your operation with the motor mounted on either the top or bottom of the cutting frame. Product Features: • Tool life is several times as long as that for shearing-cut (reciprocating cut) machines • Greasing is the only maintenance requirement • The machines are designed on many years experience. Various improvement suggested by users have been introduced for higher efficiency and convenience in practical use • These patented waving-cut machines are simple in construction, yet very durable • High-accuracy cutting of thickness from 0.002"" is ensured without tool clearance adjustment • It is not necessary for the machines to be synchronized with presses and require little floor space • There is no possibility for presses, dies or feed gears to be damaged by the machines • Heavy duty machines with no equal in the metal stamping industry General: Manufacturer: Durant Model Name: Scrap Cutter Model Number: MSC-600-SR Inventory Number: 0920-035-0006 Specifications: Maximum Thickness: .160 Maximum Width: 20 in. Reduction Gear Ratio: 1:17 Speed (SPM): 102 Motor (HP): 5 Capacity: 24 in. OPENING Weight (lb): 2305 lbs. Bay: 2700 Aisle: 04A " 0920-041-0023 Nelmore, G1215M1, Granulator, 15 HP Capacity, 1745 Rpm, 2170 lbs. " Product Overview: Nelmor G1215M1 granulator. 12″ x 15″ feed throat, 15HP 208-230/460V motor. Single wall tray feed hopper. Nelmor model F410, side mounted, 1HP swing out blower. Discharged with a 4″ outlet and aluminium impeller. Mounted on casters, complete with starter and controls for the blower and granulator. Product Features: • 3 Knife Solid Rotor • 2 Bed Knives • Double Walled Hopper • 4"" Airveyor Discharge • With Start/Stop Push Buttons General: Manufacturer: Nelmore Model Name: Granulator Model Number: G1215M1 Inventory Number: 0920-041-0023 Series: 82017194 Make Year: 1982 Specifications: Capacity: 15 HP Weight (lb): 2170 lbs. Bay: 3500 Aisle: 07A " 1020-181-0010 Cim, ME2000, Metal Embosser, 24.8W x 29.1D x 15H in., 260 lbs. " Product Overview: The ME2000 is a reliable and cost effective alternative to stamping and dies that is flexible and easy-to-use. With automatic feeding, loading and unloading metal plates has never been easier. Equipped with a unique clamp for plates of most dimensions and materials as well as a large selection of fonts, the ME 2000 is designed to meet most requirements in metal plate marking. With various command protocols, the ME 2000 can easily interface with custom applications. Product Features: Emboss or deboss on: • Automotive and VIN plates • Cable/ hose tags • Inventory/ asset control metal plates • Work in progress identification tags • Serial number tags • Military ID tags Used by: • Military • Steel plants • Manufacturers • Oil refineries • Power plants • Utility companies • Shipyards Ideal for: • Product ID • Work-in-progress • Inventory control • Facility tagging • Asset ID General: Manufacturer: Cim Model Name: Metal Embosser Model Number: ME2000 Inventory Number: 1020-181-0010 Series: M300815 Make Year: 2002 Specifications: Plates and Feeder: Plate Width: 30 - 115 mm/1.18 - 4.53 in. wide Plate Height: 21 - 90 mm/0.83 - 3.54 in. high Thickness: 0.4 - 0.9 mm/0.0157 - 0.0354 in. Input Hopper: 250 Plates Capacity (0.4 mm/0.0157 in.) Output hopper: 250 Plates Capacity Output options: FIFO Technology or Side Eject Materials: Stainless Steel, Carbon Steel, Aluminium, Copper, and Brass Stamping: Embossing, Indent, or Debossing 60 or 90 Slots Drum Capacity Performance of one 55 character plate every 18 seconds Embossing Type Set: Simplex 2, OCRB1, Block USA, Double Block, etc. Height 3 - 12 mm / 0.118 - 0.472 in. Indenting Type Set: Simplex1, Simplex 2, etc. Height 1 - 4 mm / 0.039 - 0.157 in. Debossing Type Set: Elite Dog Tag Embossing Area: From the top edge down to 65 mm / 2.56 in Leaves free 4 mm / 0.157in at the bottom edge Reverse character sets available to emboss bottom edge Measurements taken from the base of the character Communication: RS232 serial port and isolated USB to RS232 converter Software: PowerTag application with Windows 7/8/10 CIM, Xon-Xoff, MultiEmbosser, and Pound-Pound protocols Stored Format default and Stored Format Select protocols LCD edit via external keyboard; 20 downloadable formats Application Software: Automatic data field, plate archive, DBIII, DBIV, Excel, MS access file compatibility, self diagnostics, automatic rejected plates remake, and resettable/non-resettable counters Data Format: 50 fields of 42 characters each Variable, Fixed data, Counters, etc Hardware: 100 - 117 - 220 - 230 or 240V power supply - 50 or 60 Hz 800W max power consumption Operating Temperature: 5 - 40 °C / 41 - 104 °F Operating Relative Humidity: 30% ÷ 90% non condensing Dimensions (W x D x H): 630 x 740 x 380 mm/24.8 x 29.1 x 15 in. Weight (lb): 260 lbs. Bay: 3400 Aisle: 03B " https://www.dogtagmachines.com/brochures/ME2000%20OPERATOR%20MANUAL.pdf 1020-181-0012 Cim, ME2000, Metal Embosser, 24.8W x 29.1D x 15H in., 190 lbs. " Product Overview: The ME2000 is a reliable and cost effective alternative to stamping and dies that is flexible and easy-to-use. With automatic feeding, loading and unloading metal plates has never been easier. Equipped with a unique clamp for plates of most dimensions and materials as well as a large selection of fonts, the ME 2000 is designed to meet most requirements in metal plate marking. With various command protocols, the ME 2000 can easily interface with custom applications. Product Features: Emboss or deboss on: • Automotive and VIN plates • Cable/ hose tags • Inventory/ asset control metal plates • Work in progress identification tags • Serial number tags • Military ID tags Used by: • Military • Steel plants • Manufacturers • Oil refineries • Power plants • Utility companies • Shipyards Ideal for: • Product ID • Work-in-progress • Inventory control • Facility tagging • Asset ID General: Manufacturer: Cim Model Name: Metal Embosser Model Number: ME2000 Inventory Number: 1020-181-0012 Series: M401014 Make Year: 2003 Specifications: Plates and Feeder: Plate Width: 30 - 115 mm/1.18 - 4.53 in. wide Plate Height: 21 - 90 mm/0.83 - 3.54 in. high Thickness: 0.4 - 0.9 mm/0.0157 - 0.0354 in. Input Hopper: 250 Plates Capacity (0.4 mm/0.0157 in.) Output hopper: 250 Plates Capacity Output options: FIFO Technology or Side Eject Materials: Stainless Steel, Carbon Steel, Aluminium, Copper, and Brass Stamping: Embossing, Indent, or Debossing 60 or 90 Slots Drum Capacity Performance of one 55 character plate every 18 seconds Embossing Type Set: Simplex 2, OCRB1, Block USA, Double Block, etc. Height 3 - 12 mm / 0.118 - 0.472 in. Indenting Type Set: Simplex1, Simplex 2, etc. Height 1 - 4 mm / 0.039 - 0.157 in. Debossing Type Set: Elite Dog Tag Embossing Area: From the top edge down to 65 mm / 2.56 in Leaves free 4 mm / 0.157in at the bottom edge Reverse character sets available to emboss bottom edge Measurements taken from the base of the character Communication: RS232 serial port and isolated USB to RS232 converter Software: PowerTag application with Windows 7/8/10 CIM, Xon-Xoff, MultiEmbosser, and Pound-Pound protocols Stored Format default and Stored Format Select protocols LCD edit via external keyboard; 20 downloadable formats Application Software: Automatic data field, plate archive, DBIII, DBIV, Excel, MS access file compatibility, self diagnostics, automatic rejected plates remake, and resettable/non-resettable counters Data Format: 50 fields of 42 characters each Variable, Fixed data, Counters, etc Hardware: 100 - 117 - 220 - 230 or 240V power supply - 50 or 60 Hz 800W max power consumption Operating Temperature: 5 - 40 °C / 41 - 104 °F Operating Relative Humidity: 30% ÷ 90% non condensing Dimensions (W x D x H): 630 x 740 x 380 mm/24.8 x 29.1 x 15 in. Weight (lb): 190 lbs. Bay: 3000 Aisle: 03A " https://www.dogtagmachines.com/brochures/ME2000%20OPERATOR%20MANUAL.pdf 1118-070-1950 Hotsy, HWE-402009C/5115, Hot Water Pressure Washer, Belt Drive, 34L x 25W x 52H in., 615 lbs. " Product Overview: The HWE Series is powered and heated by electricity, making it ideal for indoor use. It’s a quiet machine with no fumes, making it ideal for food service and in-plant cleaning. Water is heated in a stainless steel heating coil, immersed in a tank of water solution, allowing for instant hot water once you pull the trigger. The heating elements do not come in contact with the pressurized water, which results in less maintenance and minimizes scale build up. The HWE features a Baldor motor, which drives a belt-drive Hotsy Triplex pump, with 7-year limited warranty, and an insulated variable pressure wand. ETL certified. Float switch is standard on the HWE Series. All models equipped with a 50’ hose. Product Features: • Electrically Heated and Powered • 3.5 to 4 GPM • 2000 to 3000 PSI (Operating Not Max) • 5 to 7.5 HP Industrial Electric Motor • Belt-Drive Hotsy® Triplex Pump • Many options to make industrial cleaning faster and easier General: Manufacturer: Hotsy Model Name: Hot Water Pressure Washer Model Number: HWE-402009C/5115 Inventory Number: 1118-070-1950 Series: 11096460-100485 Specifications: GPM: 4.0 PSI: 2000 HP: 6.2 Motor: Baldor Amps: 55 Volt/PH: 460/3 KvA Hour: 40.5 BTU/HR: 138,308 Pump Model: HM4030R.3 Drive: Belt Dimensions: 34L x 25W x 52H in. Weight (lb): 615 lbs. Bay: 2900 Aisle: 11B " https://s1.kaercher-media.com/media/file/57713/hotsy-operator-manual-hwe-series.pdf 1220-026-0019 Abb, IRC5 M2004, Robot Controller, Floor Mounting, 0.05 mm Repeatability, 480 lbs. " Product Overview: The ABB IRC5 M2004 Controller gives our robots the ability to perform their tasks in a highly efficient manner. Based on advanced dynamic modeling, the ABB IRC5 M2004 Controller automatically optimizes the performance of the robot by reducing cycle times (QuickMove®) and providing precise path accuracy (TrueMove®). ABB IRC5 M2004 Controllers technology, a robot’s motion is predictable and its performance high, with no tuning required by the programmer. Product Features: ABB IRC5 M2004 Single Cabinet Controller: • Designed for high IP protection and full expandability • Provides a protected environment for axillary equipment in the robot system • Capable of control of up to four robots in a MultiMove® setup. Just add a compact drive module to each additional robot • MultiMove® opens up previously unthinkable operations, thanks to the perfect coordination of complex motion patterns Applications: • Vision systems • Arc welding • Laser welding • Plasma welding • Laser cutting • Plasma cutting General: Manufacturer: Abb Model Name: Robot Controller Model Number: IRC5 M2004 Inventory Number: 1220-026-0019 Series: 66-54256 Make Year: 2006 Specifications: Axis motion speed Axis 1: 180º / s Axis 2: 180º / s Axis 3: 180º / s Axis 4: 320º / s Axis 5: 380º / s Axis 6: 460º / s Load capacity: 0/4 kg Range: 1.50 mm N axes: 6 Robot weight: 250 kg Mounting: Floor Payload: 4 kg Maximum Reach: 1500 mm Repeatability: 0.05 mm Weight (lb): 260 lbs. Bay: 3400 Aisle: 03B " http://serioussurvivor.com/wp-content/uploads/2017/03/IRC5-Product-Manual-3HAC021313-001_RevK_en.pdf https://library.e.abb.com/public/e6617595547fc6c2c1257cc5004451bd/Operating%20manual_Trouble%20shooting_3HAC020738-001_revK_en.pdf
