This item has been SOLD.
Inventory No.
0120-063-0001
Manufacturer
Krasser
Model No.
CENTURIO
Name
Slitting System
Arrival Date
Dimensions L x W x H (inches)
Unavailable
Capacity
#20,000
Electrical
-
Weight (lb.)
1
Category
Condition
See Details
Available Quantity
1
Serial No.
-
Make Year
2015
Item Details
Year 2015, 4 Wide 34 Station Coil Warehouse, Automatic Slit, Cut And Straighten, 8 Slitting Knives, Located In Ar. If Interested Please Call John Miller @ 636-222-0098 Or Email [email protected]. 0120-063-0001
About This Item
| Maximum width of the strip | 1,250 mm / 1,500 mm |
| Sheet thickness steel up to 400 N / mm | 0.4 mm - 1.2 mm (optional 1.5 mm) |
| Sheet thickness of rustproof metals up to 550 N / mm | 0.4 mm - 1 mm |
| Sheet thickness aluminum (AlMg3) / copper | 0.5 - 1.8 mm / 2 mm |
| Minimum bandwidth | 75 mm |
| Straightener (automatically adjustable) | 5 or 7 straightening rolls |
| Maximum cutting speed | 35 m / min |
| cutting accuracy | Class "m" DIN / ISO 2768 (0.8 mm / m) |
| Blade gap adjustment | 0 - 0.3 mm |
| longitudinal division | using up to 8 roller shears |
| cross members | using beam shears (optional roller shears) |
| Coillagerplatze | unlimited |
| Maximum coil weight | 5,000 kg |
| Maximum outside diameter of the coils | 1,100 mm |
| Spreading area of the coil axis | 450 - 580 mm (optional 650 mm) |
| power supply | 3PH 400-488 V AC / N / PE |
| compressed air | 150 l / min 6 bar |
